Stage 2 - Websocket Management | Tradovate Partner API

Websocket connections are essential for real-time data streaming and order management in the Tradovate API. This stage validates your integration’s ability to maintain stable websocket connections and handle real-time events.

Overview

The websocket management stage ensures your application can:

Establish and maintain websocket connections
Handle authentication over websocket
Process real-time events
Manage connection heartbeats and reconnection logic
Handle rate limiting and synchronous requests

Required Tests

Purpose: Authenticate websocket connection using access token.

Test Steps:

Establish websocket connection to wss://demo.tradovateapi.com/v1/websocket
Send authentication message with valid access token
Verify successful authentication response
Test with invalid/expired token to ensure proper error handling

Example Implementation:

const ws = new WebSocket('wss://demo.tradovateapi.com/v1/websocket');
ws.onopen = function() {
    // Send authentication message
    const authMessage = `authorize\n0\n\n${accessToken}`;
    ws.send(authMessage);
};
ws.onmessage = function(event) {
    const data = JSON.parse(event.data);
    if (data.i === 0) {
        // Authentication response
        console.log('Authentication successful:', data);
    }
};

Expected Authentication Response:

{
    "i": 0,
    "s": 200
}

Expected Error Response:

{
    "i": 0,
    "s": 401
}

Validation Criteria:

✅ Websocket connection establishes successfully
✅ Authentication succeeds with valid token
✅ Authentication fails with invalid token
✅ Connection remains stable after authentication

2. Heartbeats

Purpose: Maintain connection health and detect disconnections.

Test Steps:

Send periodic heartbeat messages
Verify heartbeat responses are received
Test heartbeat timeout scenarios
Verify connection recovery after missed heartbeats

Example Implementation:

// Track last message time
let lastMessageTime = new Date().getTime();
ws.onmessage = function(event) {
    const timestamp = new Date().getTime();
    if(timestamp - lastMessageTime > 2500) {
        ws.send('[]'); // Empty frame is a heartbeat in our protocol
        lastMessageTime = timestamp; // Update last message time
    }
    // carry on with message handling
    // ...
};

Validation Criteria:

✅ Heartbeats are sent at regular intervals
✅ Heartbeat mechanism works during high message volume

3. Event Handling

Purpose: Process real-time events from the websocket.

Test Steps:

Manage real-time subscriptions
- Start event streaming using user/syncrequest
- subscribe to relevant entity types using the entityTypes parameter
Process incoming events

Example user/syncrequest:

// Connect to the websocket
const ws = new WebSocket('wss://demo.tradovateapi.com/v1/websocket');
const requestBody = {
    splitResponses: true,
    // Optional, define sharding expression
    shardingExpression: {
        expressionType: 'modUserId', // | 'modAccountId'
        divisor: 1,   // each instance should have the same divisor
        remainder: 0, // modulus of the ID of user or account to process on this instance
    },
    entityTypes: [
        'account',
        'accountRiskStatus',
        'cashBalance',
        'commandReport',
        'command',
        'executionReport',
        'fill',
        'fillPair',
        'order',
        'orderStrategy',
        'position',
        'product',
        'user'
    ],
}
ws.onopen = function() {
    ws.send(`authorize\n0\n\n${accessToken}`);
}
ws.onmessage = function(event) {
    const type = event.data.slice(0, 1);
    let data = null;
    if(type === 'a') {
        data = JSON.parse(event.data.slice(1));
    }
    if(data.i === 0) {
        // Authentication response
        console.log('Authentication successful:', data);
        // Send syncrequest
        ws.send(`user/syncrequest\n1\n\n${JSON.stringify(requestBody)}`);
    }
}
ws.onerror = function(event) {
    console.error('WebSocket error:', event);
}

Validation Criteria:

✅ Only one syncrequest is sent per socket lifecycle.
✅ Real-time events are received
✅ Sharding is implemented correctly
✅ Entity types are subscribed to correctly
✅ Syncrequest is sent correctly
✅ Event handlers are robust and don’t crash on malformed data

4. Rate Limit Handling (P-Ticket)

Purpose: Handle rate limiting and priority ticket system.

For what penalty tickets are, what triggers them, and how to recover, see Penalty Tickets.

Test Steps:

Send requests that trigger rate limiting
Verify P-Ticket system responses
Implement proper queuing and retry logic
Test priority handling for different request types

Example Implementation:

const send = requestData => {
    return new Promise((res, rej) => {
        let i = ++lastId;
        let race = setTimeout(() => { reject(new Error('Request timeout'))}, 30000);
        function handler(event) {
            const type = event.data.slice(0, 1);
            if(type === 'a') {
                const data = JSON.parse(event.data.slice(1));
                // data is always an array
                for(const datum of data) {
                    if(datum.i === i) {
                        if(datum.d && 'p-ticket' in datum.d) {
                            const pTicket = datum.d['p-ticket'];
                            const pTime = datum.d['p-time'];
                            const pCaptcha = datum.d['p-captcha'];
                            const pMessage = datum.d['p-message'];
                            console.log(`Rate limit reason: ${pMessage}`);
                            if(pCaptcha) {
                                // Handle captcha, if you receive it you have been locked out for 1 hour
                                console.error('p-captcha received. Operations locked for 1 hour.');
                                return;
                            } else {
                                // Handle rate limiting with P-Ticket, resend the request
                                // with the p-ticket after p-time seconds.
                                setTimeout(() => {
                                    send({
                                        ...requestData,
                                        body: { ...requestData.body, 'p-ticket': pTicket }
                                    });
                                }, pTime * 1000);
                                ws.removeEventListener('message', handler);
                            }
                        } else {
                            clearTimeout(race);
                            res(datum.d);
                            ws.removeEventListener('message', handler);
                        }
                    }
                }
            }
        }
        // construct the message string
        const queryString = requestData.query || ''
        const bodyString = JSON.stringify(requestData.body || '')
        const messageString = `${requestData.endpoint}\n${i}\n${queryString}\n${bodyString}`;
        ws.addEventListener('message', handler);
        ws.send(messageString);
    });
}

Validation Criteria:

✅ Rate limiting responses are properly handled
✅ P-Ticket system is implemented correctly

5. Reconnection

Purpose: Automatically reconnect after connection loss.

Test Steps:

Simulate connection drops
Verify automatic reconnection logic
Test re-authentication after reconnection
Verify state recovery after reconnection

Example Implementation:

let lastMessageTime = new Date().getTime();
ws.onmessage = async function(event) {
    const timestamp = new Date().getTime();
    if(timestamp - lastMessageTime > 15000) {
        // connection has been idle for 15 seconds, reconnect
        await reconnect();
    }
    lastMessageTime = timestamp;
}

Validation Criteria:

✅ Automatic reconnection works after connection loss
✅ Re-authentication occurs after reconnection
✅ State is properly recovered after reconnection

Performance Requirements

Heartbeat: Send heartbeats every 2.5 seconds (2,500 ms)

For detailed performance requirements, contact Evaluation Support.

Testing Checklist

Websocket connection establishes successfully
Authentication works with valid tokens
Heartbeats are sent and received
Events are processed correctly
Rate limiting is handled properly
Syncrequests work as expected and are called only once per socket lifecycle
Reconnection works automatically

Next Steps

After completing Stage 2 websocket management tests, proceed to Stage 3: User Management.
